February 2, 2022 NHTSA CAMPAIGN NUMBER: 22V052000
Suspension misalignment may cause premature or uneven tire wear, increasing the risk of a crash.
NHTSA Campaign Number: 22V052
Manufacturer Porsche Cars North America, Inc.
Components SUSPENSION, TIRES
Potential Number of Units Affected 1
Summary
Porsche Cars North America, Inc. (Porsche) is recalling one 2021 Taycan vehicle. The front and rear suspension may be misaligned.
Remedy
Dealers will inspect the front and rear axles, adjust the alignment as necessary, and replace any prematurely or unevenly worn tires, free of charge. The owner notification letter was mailed March 10, 2022. Owners may contact Porsche customer service at 1-800-767-7243. Porsche’s number for this recall is ANA2.
Notes
Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.nhtsa.gov.
Check if your Porsche has a Recall
Model Line: Taycan (Y1A)
Model Year: 2021
Concerns: Suspension alignment
Information:
On the affected vehicles, there is a possibility that the suspension settings on the front and rear axles do not comply with the specifications.
Faulty suspension adjustment can lead to uneven tire wear with higher mileage/km.
As a result, high-speed stability and traction may be restricted at high vehicle speeds.
Action required: Measure the vehicle and correct if necessary.
Information
If the suspension adjustment is not in order, the tires on the front and/or rear axle must be replaced if the tires are worn on one side. In addition, the tires of the 2nd wheel set (if present) must be checked for one-sided tire wear and replaced if necessary.
Affected Vehicles:
Only vehicles assigned to the campaign (see also PCSS Vehicle Information).
Chronology :
December 7, 2021, Porsche was informed that certain Taycan vehicles may have been produced with incorrect setting of the camera measuring ranges in the axle setting device in production. Subsequently, an investigation was carried out to identify possible consequential damage to the tires and whether complaints had already been received from the field.
In parallel, the affected vehicles had to be identified.
January 26, 2022: Porsche`s Product Safety Committee determined that the affected vehicles may be not within specification regarding the suspension alignment and that a sudden loss of air pressure cannot be ruled out.
The decision for a voluntary safety recall was made.
1 Affected Product
Vehicle
MAKE | MODEL | YEAR |
PORSCHE | TAYCAN | 2021 |
7 Associated Documents
Defect Notice 573 Report
RCLRPT-22V052-9985.PDF 213.786KB
Recall Acknowledgement
Remedy Instructions and TSB
RCRIT-22V052-7100.pdf 86.494KB
ISSUED Owner Notification Letter(Part 577)
RCONL-22V052-6085.pdf 368.736KB
Manufacturer Notices(to Dealers,etc) – Email
RCMN-22V052-6592.pdf 204.302KB
Recall Quarterly Report #1, 2022-1
RCLQRT-22V052-8937.PDF 211.133KB
Recall Quarterly Report #2, 2022-2
RCLQRT-22V052-8459.PDF 211.232KB
